Xiaomi diting Community

Guides

Command line

For advanced users, installing /e/OS with Android platform tools.

Install
Build

Build /e/OS for yourself with your own settings.

Build

Boot Modes

Recovery

With the device powered off - hold Volume Up + Power.Keep holding both buttons until the "MI" logo appears on the screen, then release.

Download

With the device powered off - hold Volume Down + Power. Keep holding both buttons until the word "FASTBOOT" appears on the screen, then release.

Support the project

Join the testing community Report an issue about diting Contribute Donate

Usability

Known issue(s) 0

12T Pro

diting

Apps Compatibility

Safetynet
✅
Rootbeer
✅

Bootloader relocking support

Data unavailable

See something wrong? Help us update this info.

Verified boot support

Data unavailable

See something wrong? Help us update this info.

Device details

Release
2022
SoC
Qualcomm SM8475 Snapdragon 8+ Gen1
RAM
8/12 GB LPDDR5
CPU
Octa-core Kryo
1 x 3.19 GHz + 3 x 2.75 GHz + 4 x 1.8 GHz
Architecture
arm64
GPU
Qualcomm Adreno 730
Network
  • 2G bands: GSM
  • 2G bands: CDMA
  • 3G bands: UMTS
  • 4G bands: LTE
  • 5G bands: NR
Storage
128/256 GB UFS 3.1
SD card
–
Screen
6.67 in
1220x2712 ( PPI)
AMOLED (max 120 Hz)
Device Tree
android_device_xiaomi_diting
Bluetooth
5.2 with A2DP + aptX HD
Wi-Fi
802.11 a/b/g/n/ac/ax
Peripherals
  • A-GPS
  • Accelerometer
  • Compass
  • Dual SIM
  • Dual speakers
  • Dual-frequency GNSS
  • Fingerprint reader
  • BeiDou
  • Galileo
  • GLONASS
  • GPS
  • NAVIC
  • QZSS
  • Gyroscope
  • IR blaster
  • Light sensor
  • NFC
  • Proximity sensor
  • USB OTG
Camera(s)
No of Cameras: 4
  • 200 MP (wide angle), Dual LED (dual tone) flash
  • 8 MP (ultra-wide angle), Dual LED (dual tone) flash
  • 2 MP (macro), Dual LED (dual tone) flash
  • 20 MP (front), None flash
Dimensions
163.1 mm (h)
75.9 mm (w)
8.6 mm (d)
Battery
Non-removable Li-Po 5000 mAh

/e/OS Information

Maintainers
  • /e/OS Build Team
Build versions
  • A15 (community)
Models Supported
Models:
  • 22081212UG
  • 22081212R
  • 22200414R
  • A201XM
Other models are not supported
Disclaimer: We cannot guarantee that all the device specific information on this page is 100 % up to date or accurate. Read more.
